Torque range

1000 ... 1287000  Nm

Rated mechanical power (n1 = 1500 rpm)

Upper limit 450 kW

Transmission ratio

3.4 ... 5234

Reduction gear type

Coaxial

Right angle (with Gleason bevel gear set)

Output type
Base and flange mounting

Output shaft: keyed solid shaft, splined shaft, splined hollow shaft, hollow shaft with locking disk

Input type
IEC and NEMA motor interface
Solid input shaft with cooling fan, imperial or metric sizes.

Applicable AC motors
Integrated motors and brake motors - M series / ME series
IEC standard motors and brake motors - BN series / BE series
Single and dual speed motors

Main braking characteristics
DC and AC supply
Fast braking possible with electronically controlled rectifiers

Main motor options
Thermistors and thermostats
Separate forced cooling system
Line drivers and push-pull incremental encoders

Torque
