Industrial application solutions
Torque range
4650 ≤ MN2 ≤ 75000 Nm
Transmission ratio
7.1 ≤ iN ≤ 125.0, speed series φ = 1.12
Mounting type
Base mounting
Output shaft
Thrust bearings of different sizes and load capacities and hollow shafts of different shapes and sizes.
The standard shaft is a keyed hollow shaft in accordance with UNI 6604.
Mounting dimensions to customer specifications available
Input type
Solid shaft, direct motor mounting, cage housing with flexible coupling
Options
Cooling coil, automatic cooling, temperature and oil level sensor
Torque
|
Model |
Torque (Nm) |
|
HDPE 60 |
4650 |
|
HDPE 70 |
6350 |
|
HDPE 80 |
11500 |
|
HDPE 90 |
16550 |
|
HDPE 100 |
24000 |
|
HDPE 110 |
28700 |
|
HDPE 120 |
35300 |
|
HDPE 130 |
59300 |
|
HDPE 140 |
75000 |
