• Torque range
  150 ... 16000 Nm




• Mechanical rated power (n1 = 900 rpm)

         1.1 ... 156 KW

• ratio

  5.0 ... 31.5




• Output type

  Keyed hollow shaft
  Up to three bore options per model




• Gearbox

  Rugged cast housing, suitable for outdoor installation




• Backstop

  Applicable to all models - external loading and unloading




• Torque


  Model	Torque (Nm)
  TA 30	150
  TA 35	400
  TA 40	900
  TA 45	1.350
  TA 50	2.100
  TA 60	3.500
  TA 70	4.900
  TA 80	6.600
  TA 100	10.500
  TA 125	16.000
